Description
| Beam | 12 line | Self-leveling range | ±3° | |
| Laser diode | 532nm/5mW | Working range | 30m(with detector) | |
| Anti-dust&Antl-water | IP-20 | Power supply | Li-ion battery | |
| Laser safety class | Class II | Mounting thread | 5/8x11,UNC standard | |
| Accuracy | ±1.5mm/5m | Range of operating temperature | -10℃ ~ +40℃ | |
| Packing: | ||||
| Intrument size | 135x90x130mm | Unit packing size | 40x15x35cm | |
| Intrument weight | 0.75kg | Unit packing weight: | 1.8KG | |
| Standard accessory | Li-ion battery; manual;box | Carton dimensions | 51x40x17cm /4pcs | |
| glasses; adapter; Base(optional) | Carton weight: | 9.2/7.2kgs | ||
| Carton capacity | 4pcs |
